Stainless Steel 347/347H Forged Fittings Manufacturer and Supplier in Chennai, India
Based in Chennai, India, we take pride in being a reliable manufacturer and supplier of Stainless Steel 347/347H Forged Fittings. We deliver top-notch forged components that are perfect for demanding industrial applications. These fittings are crafted to excel in high-temperature and corrosive environments, making them a go-to choice for power plants, refineries, chemical processing, and aerospace systems. With their impressive resistance to intergranular corrosion and ability to maintain mechanical strength under thermal stress, SS 347/347H forged fittings are built to last. We adhere to international standards and utilize advanced forging techniques to ensure our fittings are durable, precise, and leak-proof. Our commitment to timely delivery and customized solutions has earned us the trust of both domestic and international clients.
Table of Contents
Stainless Steel 347 Threaded Fitting Price List in Chennai, UNS S34700 Stainless Steel Forged Fittings Supplier in India, Stainless Steel 347H High Pressure Forged Fittings Exporter in Chennai, Stainless Steel 347 Hex Plug Supplier in Chennai, SS 347 Threaded Pipe Elbow Exporter in Chennai, SS UNS S34709 Pipe Nipple Size Chart, Stainless Steel 347H Forged Fittings Price in India, SS 347 Screwed Fittings in Chennai, Stainless Steel 1.4961 Forged Fittings Supplier in Chennai, Stainless Steel 347H Hexagonal Plug Stockist in India, Stainless Steel 347H Forged Fittings Exporter in India
Stainless Steel 347/347H Forged Fittings Specification
| Specification | ASTM A182 / ASME SA182 |
| Dimension Standard | ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799 |
| Size | 1/8″ NB to 4″ NB |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Pressure-Temperature Class | Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS. |
Stainless Steel 347/347H Forged Fittings are a type of stabilized austenitic stainless steel, containing around 17–19% chromium and 9–13% nickel, with niobium added for stabilization. The 347H grade stands out with its higher carbon content (0.04–0.10%), which enhances its high-temperature strength and creep resistance. These fittings boast excellent oxidation resistance and impressive mechanical properties, including a tensile strength of 515 MPa, yield strength of 205 MPa, and an elongation of 40%. We offer a variety of types, including forged elbows, tees, couplings, unions, caps, and crosses, all engineered to perform reliably under high-pressure and thermal cycling conditions.
Stainless Steel 347/347H Forged Fittings Chemical Compostion
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
| SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
Stainless Steel 347/347H Forged Fittings Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
SS 347 Socket Weld Fittings Exporter in India, DIN 1.4550 Stainless Steel Union Price List in Chennai, Stainless Steel 347 Forged Fittings Supplier in India, ANSI B16.11 Stainless Steel 347H Forged Fittings Exporter in Chennai, Stainless Steel 347 Forged Elbow Exporter in Chennai, Stainless Steel 347 Forged Tee in India, SS 347 Socket Weld Fittings Size Chart, Stainless Steel 347 Coupling Price in India, UNS S34709 Stainless Steel Forged Threaded 90 deg. Elbow Weight Chart, Stainless Steel 347H Stainless Steel Cross Trader Supplier in Chennai, Stainless Steel 347 Socket weld Fittings Stockist in India
Largest Stainless Steel 347/347H Forged Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Stainless Steel 310H Forged Fittings in Chennai, India. We offer an extensive range of Stainless Steel 310H Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Stainless Steel 347/347H Forged Fittings Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN |
| SS 347 | 1.4550 | S34700 | SUS 347 | 08Ch18N12B | X6CrNiNb18-10 |
| SS 347H | 1.4961 | S34709 | SUS 347H | – | X6CrNiNb18-12 |
Pressure Rating Of Stainless Steel 347/ 347H Forged fitting
| Pressure-Temperature | |||||
| Temperature | Class | ||||
| 150 | 300 | ||||
| 1/4 – 1 inch. | 1 1/4 – 2 inch. | 2 1/2 – 3 inch. | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | – | 935 | 750 | 560 |
| 450 | 232 | – | 725 | 600 | 475 |
| 500 | 260 | – | 510 | 450 | 385 |
| 550 | 288 | – | 300 | 300 | 300 |
Why Choose Stainless Steel 347/347H Forged Fittings from Meet Fittings?
Choose Stainless Steel 347/347H Forged Fittings from Meet Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Stainless Steel UNS S34709 Full Coupling Exporter in India, SS 347 Forged Socket weld Fittings Sizes in mm, Stainless Steel 347 Forged Fittings Manufacturer in Chennai, Stainless Steel DIN 1.4550 Threaded Fittings Supplier in Chennai, ASME SA182 Stainless Steel 347H Forged Fittings Price List in Chennai, SUS 347 Forged Union Distributor in Chennai, SS UNS S34703 Forged Fittings Supplier in Chennai, Stainless Steel 347 Forged Cap Distributor in India
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Stainless steel 347/347H forged fittings offer many advantages, including exceptional resistance to intergranular corrosion due to the durable structure of columbium/tantalum They withstand high temperatures and provide excellent creep and stress-break properties on, making it ideal for high-temperature applications. These materials retain excellent strength and durability under extreme conditions, providing long-term performance. Their resistance to oxidation makes them suitable for environmental conditions involving chemical and thermal exposure. In addition, they exhibit excellent weldability and machinability, which require reliability and thermal stability in the petrochemical, aerospace and power generation industries.
Types of Stainless Steel 347/347H Forged Fittings
Are Custom Sizes Available for Stainless Steel 347/347H Forged Fittings?
Yes, custom sizes for Stainless Steel 347/347H Forged Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in
Dimension of SS 347/347H Forged Fittings
| ASME b16.9 Fittings Normal Pipe Size | ANSI b16 9 Pipe Fitting O D Y | Wall Thickness T (Pipe Elbow Sch.) | LR 45 Deg Elbows Centre to Face B | SR 45 Deg Elbows Weight | LR 90 Deg Elbows Centre to Face A | LR 90 Deg Elbows Weight In Below | SR 90 Deg Elbows Centre to Face A | SR 90 Deg Elbows Weight In Below | ||
|---|---|---|---|---|---|---|---|---|---|---|
| millimeter | inch. | millimeter | millimeter | Schedule | millimeter | kilogram | millimeter | kilogram | millimeter | kilogram |
| 15 | 1/2” | 21.3 | 2.78 | STD | 15.9 | 0.04 | 38.1 | 0.08 | – | – |
| 3.73 | X.S | 15.9 | 0.05 | 38.1 | 0.10 | – | – | |||
| 20 | 3/4” | 26.7 | 2.87 | STD | 11.1 | 0.04 | 28.6 | 0.08 | – | – |
| 3.91 | X.S | 11.1 | 0.05 | 28.6 | 0.11 | – | – | |||
| 25 | 1” | 33.4 | 3.38 | STD | 22.2 | 0.09 | 38.1 | 0.15 | 25.4 | 0.11 |
| 4.55 | X.S | 22.2 | 0.11 | 38.1 | 0.19 | 25.4 | 0.14 | |||
| 32 | 11/4” | 42.2 | 3.56 | STD | 25.4 | 0.14 | 47.6 | 0.28 | 31.75 | 0.18 |
| 4.85 | X.S | 25.4 | 0.2 | 47.6 | 0.39 | 31.75 | 0.24 | |||
| 40 | 11/2” | 48.3 | 3.68 | STD | 28.6 | 0.2 | 57.1 | 0.4 | 38.1 | 0.26 |
| 5.08 | X.S | 28.6 | 0.25 | 57.1 | 0.5 | 38.1 | 0.35 | |||
| 50 | 2” | 60.3 | 3.91 | STD | 34.9 | 0.36 | 76.2 | 0.72 | 50.8 | 0.5 |
| 5.54 | X.S | 34.9 | 0.5 | 76.2 | 1.0 | 50.8 | 0.68 | |||
| 65 | 21/2” | 73.0 | 5.16 | STD | 44.4 | 0.73 | 95.2 | 1.46 | 63.5 | 0.95 |
| 7.01 | X.S | 44.4 | 0.91 | 95.2 | 1.82 | 63.5 | 1.27 | |||
| 80 | 3” | 88.9 | 5.49 | STD | 50.8 | 1.1 | 114.3 | 2.18 | 76.2 | 1.45 |
| 7.62 | X.S | 50.8 | 1.45 | 114.3 | 2.86 | 76.2 | 1.95 | |||
| 100 | 4” | 114.3 | 6.02 | STD | 63.5 | 2.1 | 152.4 | 4.2 | 101.6 | 2.8 |
| 8.56 | X.S | 63.5 | 2.9 | 152.4 | 5.7 | 101.6 | 3.9 | |||
| 125 | 5” | 141.3 | 6.65 | STD | 79.4 | 3.4 | 190.0 | 6.8 | 127.0 | 4.8 |
| 9.5 | X.S | 79.4 | 5.0 | 190.0 | 10.0 | 127.0 | 6.5 | |||
| 150 | 6” | 168.3 | 7.11 | STD | 95.2 | 5.1 | 229.0 | 10.1 | 152.4 | 6.8 |
| 10.97 | X.S | 95.2 | 7.7 | 229.0 | 15.3 | 152.4 | 10.2 | |||
| 200 | 8” | 219.1 | 8.18 | STD | 127.0 | 10.2 | 305.0 | 20.4 | 203.0 | 13.6 |
| 12.7 | X.S | 127.0 | 15.5 | 305.0 | 30.9 | 203.0 | 20.9 | |||
| 250 | 10” | 273.9 | 9.27 | STD | 159.0 | 18.1 | 381.0 | 36.1 | 254.0 | 24.1 |
| 12.7 | X.S | 159.0 | 24.4 | 381.0 | 48.8 | 254.0 | 32.5 | |||
| 300 | 12” | 323.9 | 9.52 | STD | 190.0 | 26.6 | 457.0 | 53.1 | 305.0 | 35.4 |
| 12.7 | X.S | 190.0 | 35.0 | 457.0 | 70.0 | 305.0 | 46.7 | |||
| 350 | 14” | 355.6 | 9.52 | STD | 222.0 | 34.1 | 533.0 | 68.1 | 356.0 | 45.4 |
| 12.7 | X.S | 222.0 | 45.0 | 533.0 | 90.0 | 356.0 | 60.0 | |||
| 400 | 16” | 406.4 | 9.52 | STD | 254.0 | 45.0 | 610.0 | 89.3 | 406.0 | 59.5 |
| 12.7 | X.S | 254.0 | 59.0 | 610.0 | 118.0 | 406.0 | 78.7 | |||
| 450 | 18” | 457.0 | 9.52 | STD | 286.0 | 56.5 | 686.0 | 113.0 | 457.0 | 75.6 |
| 12.7 | X.S | 286.0 | 75.0 | 686.0 | 150.0 | 457.0 | 100.0 | |||
| 500 | 20” | 508.0 | 9.52 | STD | 318.0 | 85.0 | 762.0 | 140.0 | 508.0 | 93.5 |
| 12.7 | X.S | 318.0 | 112.5 | 762.0 | 186.0 | 508.0 | 124.0 | |||
| 600 | 24” | 610.00 | 9.52 | STD | 381.0 | 101.5 | 914.0 | 203.0 | 610.0 | 135.0 |
| 12.7 | X.S | 381.0 | 134.5 | 914.0 | 269.0 | 610.0 | 179.0 | |||
Size of Stainless Steel 347/347H Forged Fittings
| NPS (inch) | Pipe Schedule. | OD (inch) | Wall Thick. (in) | Temperature | ||||
|---|---|---|---|---|---|---|---|---|
| Duplex Steel 100 Fitting | Duplex Steel 200 Fitting | Duplex Steel 300 Fitting | Duplex Steel 400 Fitting | Duplex Steel 500 Fitting | ||||
| Allowable Stress | ||||||||
| 16700 | 16700 | 16700 | 15500 | 14400 | ||||
| 1″ | 40 | 1.315 | 0.133 | 2205 | 2205 | 2205 | 2047 | 1902 |
| 80 | 1.315 | 0.179 | 3061 | 3061 | 3061 | 2841 | 2640 | |
| 160 | 1.315 | 0.250 | 4493 | 4493 | 4493 | 4170 | 3874 | |
| 1 1/2″ | 40 | 1.900 | 0.145 | 1629 | 1629 | 1629 | 1512 | 1404 |
| 80 | 1.900 | 0.200 | 2303 | 2303 | 2303 | 2138 | 1986 | |
| 160 | 1.900 | 0.281 | 3362 | 3362 | 3362 | 3120 | 2899 | |
| 2″ | 40 | 2.375 | 0.154 | 1371 | 1371 | 1371 | 1272 | 1182 |
| 80 | 2.375 | 0.218 | 1985 | 1985 | 1985 | 1843 | 1712 | |
| 160 | 2.375 | 0.344 | 3283 | 3283 | 3283 | 3047 | 2831 | |
| 3″ | 40 | 3.500 | 0.216 | 1301 | 1301 | 1301 | 1208 | 1122 |
| 80 | 3.500 | 0.300 | 1844 | 1844 | 1844 | 1712 | 1590 | |
| 160 | 3.500 | 0.438 | 2787 | 2787 | 2787 | 2587 | 2403 | |
| 4″ | 40 | 4.500 | 0.237 | 1102 | 1102 | 1102 | 1023 | 950 |
| 80 | 4.500 | 0.337 | 1596 | 1596 | 1596 | 1482 | 1377 | |
| 160 | 4.500 | 0.531 | 2611 | 2611 | 2611 | 2424 | 2552 | |
| 5″ | 40 | 5.563 | 0.258 | 965 | 965 | 965 | 896 | 832 |
| 80 | 5.563 | 0.375 | 1428 | 1428 | 1428 | 1325 | 1231 | |
| 160 | 5.563 | 0.625 | 2474 | 2474 | 2474 | 2296 | 2133 | |
| 6″ | 40 | 6.625 | 0.280 | 877 | 877 | 877 | 814 | 756 |
| 80 | 6.625 | 0.432 | 1379 | 1379 | 1379 | 1280 | 1189 | |
| 160 | 6.625 | 0.719 | 2382 | 2382 | 2382 | 2211 | 2054 | |
| 8″ | 40 | 8.625 | 0.322 | 771 | 771 | 771 | 716 | 665 |
| 80 | 8.625 | 0.500 | 1218 | 1218 | 1218 | 1131 | 1050 | |
| 160 | 8.625 | 0.906 | 2298 | 2298 | 2298 | 2133 | 1982 | |
| 10″ | 40 | 10.750 | 0.365 | 699 | 699 | 699 | 649 | 603 |
| 80 | 10.750 | 0.594 | 1159 | 1159 | 1159 | 1075 | 999 | |
| 160 | 10.750 | 1.125 | 2289 | 2289 | 2289 | 2124 | 1974 | |
ASTM A182 SS 347 End Cap Supplier in Chennai, Stainless Steel 347 Forged Pipe Fittings Weight Chart, Stainless Steel 347H Welding Boss Exporter in India, Stainless Steel 347 High Pressure Forged Fitting Manufacturer in Chennai, WERKSTOFF NR. 1.4961 Threaded Cross Price List in Chennai, Stainless Steel 347 Threaded Fittings Sizes in mm, Stainless Steel 347H Forged Fittings Distributor in Chennai, Stainless Steel 347H 180 Deg. Street Elbow in India, Stainless Steel 347 Forged Tee Distributor in India.
Application Industry of Stainless Steel 347/347H Forged Fittings
Stainless Steel 347/347H Forged Fittings are perfect for applications that involve high temperatures and corrosive environments, particularly where welding is necessary. They are frequently used in heat exchangers, superheaters, boiler tubes, exhaust manifolds, and chemical processing lines. The niobium stabilization helps prevent carbide precipitation during welding, which reduces the risk of intergranular corrosion. With its higher carbon content, SS 347H is particularly suited for elevated-temperature services, such as those found in thermal power plants and refinery reactors. Their forged construction guarantees robust mechanical strength and outstanding reliability in high-pressure situations.
