Based in Chennai, India, we proudly stand as a top manufacturer and supplier of Hastelloy C276 Buttweld Fittings, delivering high-quality, corrosion-resistant components designed to thrive in the toughest industrial settings. Hastelloy C276 is a remarkable nickel-molybdenum-chromium alloy, celebrated for its exceptional resistance to strong oxidizers, reducing agents, and a variety of aggressive chemicals. Our buttweld fittings are crafted to meet international standards like ASTM B366, ensuring they are precise, durable, and leak-proof. These fittings find extensive application in industries such as chemical processing, waste treatment, pollution control, marine, and pharmaceuticals, where extreme corrosion resistance is a must.
Hastelloy Buttweld Fittings Manufacturer and Supplier in Chennai, India
Table of Contents
C-276 Hastelloy Welded Pipe Fittings Suppliers India, C276 Hastelloy® ANSI B16.9 Short & Long Radius Elbow Chennai, C276 Hastelloy 45°/90°/180° Butt weld Elbow Chennai, Distributors of Hastelloy® Alloy C276 ASME SB366 Buttweld Reducer in Chennai, ASME B16.28 C-276 Hastelloy® Alloy Butt weld Reducing Tee India, C276 Hastelloy Unequal Cross Exporters Chennai, C276 Hastelloy Welded Fittings In India.
Hastelloy C276 Buttweld Fittings Specification
| Specifications | ASTM B366 / ASME SB366 |
| Dimension Standard | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| ASME B16.9 | standard for – Factory-Made Wrought Buttwelding Fittings |
| ASME B16.25 | Buttwelding Ends. |
| ASME B16.28 | standard for – Butt-Welded Short Radius Elbows & Returns Bends |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Seamless Butt Weld Fitting Size | 1/2″ – 10″ |
| Welded Butt Weld Fittings Size | 1/2″ – 48″ |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Type | Seamless / Welded / Fabricated |
Hastelloy C276 Buttweld Fittings Chemical Composition
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Hastelloy C276 | Balance | 0.01 max | 15 – 17 | 1.0 max | 0.08 max | 4 – 7 | 0.04 max | 0.03 max | 2.5 max | 14.5 – 16.5 |
Hastelloy C276 Buttweld Fittings Equivalent Grade
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Hastelloy C276 Buttweld Fittings are made up of about 57% nickel, 15.5% chromium, 16% molybdenum, 5% iron, and 3.5% tungsten. This unique blend offers remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking in both oxidizing and reducing environments. The fittings boast a tensile strength of around 760 MPa, a yield strength of approximately 283 MPa, and impressive ductility with about 60% elongation. Available in both seamless and welded forms, our range includes elbows, tees, reducers, caps, and stub ends, all designed for high-pressure and high-temperature piping systems.
Hastelloy C276 Buttweld Elbow Dimensions Standard
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | ELBOWS AND TEES | 180 DEG RETURN BENDS | 180 DEG RETURN BENDS | 180 DEG RETURN BENDS | REDUCERS | CAPS |
|---|---|---|---|---|---|---|---|---|
| NPS | O.D. at Bevel (1), (2) | I.D. at End (1), (3), (4) | Centre -to- End Dimension A, B, C, M | Centre-to- Centre O | Back-to- Face K | Alignment of Ends U | Overall Length H | Overall Length E |
| ½ to 2½ | 0.06 -0.03 | 0.03 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 3 to 3 ½ | 0.06 | 0.06 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 4 | 0.06 | 0.06 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 5 to 8 | 0.09 -0.06 | 0.06 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
| 10 to 18 | 0.16 -0.12 | 0.12 | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 20 to 24 | 0.25 -0.19 | 0.19 | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 26 to 30 | 0.25 -0.19 | 0.19 | 0.12 | … | … | … | 0.19 | 0.38 |
| 32 to 48 | 0.25 -0.19 | 0.19 | 0.19 | … | … | … | 0.19 | 0.38 |
Nickel Alloy C-276 Buttweld Fittings India, Nickelvac® HC-276 Butt weld Pipe Fittings Chennai, Hastelloy C-276 Equal Tee Wholesaler Chennai, ASTM B366 Hastelloy C276 Pipe Elbow Chennai, C276 Hastelloy® Buttweld Tee Dealer In India, Hastelloy C-276 Pipe Fittings Chennai, Hastelloy® C276 Pipe Fittings India.
Largest Hastelloy C276 Buttweld Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Hastelloy C276 Buttweld Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Hastelloy C276 Buttweld Fittings Dimensions Standard
| All Fittings | 90°and 45° Ells and Tees | Reducers and Lap Joint Stub | Caps | 180° Returns | Angularity Tol | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Pipe Plane Size (NPS) | Outside(1) Diameter at Bevel | Inside(1) Diameter at End | Wall(2) Thickness | Centre-to- End Dimension A,B,C,M | Overall Length L | Overall Length E | Centre-to- Centre Dimension O | Back-to- Face Dimension K | Alignment at Ends U | Nominal Pipe SIze | Off Angle Q | Off Angle P |
| 1/2 TO 2-1/2 | +1/16 | ±1/32 | Not less than 87-1/2% of Normal Thickness | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 12 to 4 | 1/32 | 1/16 |
| -1/32 | 5 to 8 | 1/16 | 1/8 | |||||||||
| 3 TO 3-1/2 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 10 to 12 | 3/32 | 3/16 | |
| 4 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 14 to 16 | 3/32 | 1/4 | |
| 5 TO 8 | +1/32 | ±1/16 | ±1/16 | ±1/16 | ±1/4 | ±1/4 | ±1/4 | ±1/32 | 18 to 24 | 1/8 | 3/8 | |
| -1/16 | ||||||||||||
| 10 TO 18 | +1/16 | ±1/8 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | All dimensions are in inches | |||
| -1/8 | ||||||||||||
| 20 TO 24 | +1/4 | ±3/32 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | ||||
| -3/32 | ||||||||||||
Why Choose Hastelloy C276 Buttweld Fittings from Meet Fittings?
Hastelloy C276 Buttweld Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Hastelloy Grade C-276 Butt weld Pipe Fittings Stockists In India, Alloy C276 Pipe Fittings Suppliers Chennai, UNS N10276 Nickel Alloy Butt weld Seamless Pipe Fitting Chennai, Werkstoff No 2.4819 Hastelloy® Butt weld Eccentric Reducer Traders Chennai, Alloy C-276 MSS-SP-43 Buttweld Swage Nipple India, C276 Nickel Alloy Concentric Reducer Chennai, MSS SP-79 Hastelloy C-276 End Pipe Cap Suppliers India, Hastelloy® Alloy JIS NW 0276 C276 Stub Ends Exporters India, Nicrofer® 5716 Pipe Fittings Chennai, India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Hastelloy C276 Buttweld Fittings offer numerous advantages, making them ideal for challenging environments. Their superior resistance to corrosion, including pitting, stress-corrosion cracking, and oxidation, ensures long-lasting performance in aggressive chemical processes. These fittings maintain strength and integrity even in high-temperature and highly acidic or alkaline conditions. With exceptional weldability and formability, Hastelloy C276 allows for easy fabrication into various shapes. Its excellent durability and low maintenance needs make it cost-effective over time. These properties make it a preferred choice for industries like chemical processing, power generation, and marine applications.
Types of Hastelloy C276 Buttweld Fittings
Are Custom Sizes Available for Hastelloy C276 Buttweld Fittings?
Yes, custom sizes for Hastelloy C276 Buttweld Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Werkstoff No 2.4819 Hastelloy® Butt weld Eccentric Reducer Traders India, Alloy C-276 MSS-SP-43 Buttweld Swage Nipple Chennai, C276 Nickel Alloy Concentric Reducer Chennai, MSS SP-79 Hastelloy C-276 End Pipe Cap Suppliers Chennai, Hastelloy® Alloy JIS NW 0276 C276 Stub Ends Exporters India, Nicrofer® 5716 Pipe Fittings Chennai, Hastelloy C276 Buttweld Fittings India.
Application Industry of Hastelloy C276 Buttweld Fittings
Hastelloy C276 Buttweld Fittings are perfect for use in highly corrosive environments, such as chemical reactors, flue gas scrubbers, heat exchangers, pressure vessels, and offshore systems. They are particularly effective for handling acids like hydrochloric, sulfuric, nitric, and phosphoric acids, even in welded configurations. These fittings maintain their mechanical integrity under thermal cycling and aggressive chemical exposure, ensuring safe and long-lasting performance. With their outstanding corrosion resistance, high mechanical strength, and excellent weldability, Hastelloy C276 buttweld fittings are the go-to choice for critical piping systems in extreme industrial conditions.
