| Spec Chart Of: | Incoloy 825 Pipe Fittings |
| Dimension Table Of: | ANSI B16.9, JIS B2312, MSS-SP-43 Type B, ASME B16.28, JIS B2313, MSS-SP-43 Type A |
| Fittings Materials Directory: | Iron (Ductile/Cast), Carbon Steel, Titanium, Nickel Alloys, Nickel, Cupro-Nickel 90/10 & 70/30, Brass, Bronze, Copper, Chrome-molybdenum, Inconel, Monel, Tantalum, Stainless Steel, Hastalloy, Alloy Steel |
| Size Calculation: | Normal Pipe Size (1⁄₂”) to Normal Pipe Size (48”) |
| Standard Fittings Chart | JIS, NPT, ISO, DIN, EN |
| Manimum Pressure | Class 150# To Class 2500#. |
| Schedule Chart: | Schedule 5s/ Schedule 10s/ Schedule 40/ Schedule 80/ Schedule 120/ Schedule 160. |
| Most Demanded Fittings Types | Adapter, 4 Wye, End Cap, Stub End, Reducer, Cross, Bend, Elbow, Tee |
| Buttweld Fittings Connection Type | Threaded/ Weld/ Flange/ Clamp End / End Bell |
Incoloy 825 Pipe Fittings Manufacturer and Supplier in Chennai, India
Meet Fittings, being based in Chennai, India, is a well-known manufacturer and supplier of **Incoloy 825 Pipe Fittings**, famous for their high level of corrosion resistance and mechanical strength. These pipe fittings are made from Incoloy 825, a nickel-iron-chromium alloy that is enriched with molybdenum, copper, and titanium and is renowned for its very high resistance to both oxidizing and reducing environments. Meet Fittings provides a complete array of Incoloy 825 pipe fittings like elbows, tees, reducers, caps, and crosses that are produced as per international standards. The fittings find extensive application in chemical processing, marine, pollution control, and acid production fields.
Table of Contents
UNS N08825 Elbow And Most Reliable Alloy 825 Tubing Fittings India, Incoloy 825 Pipe Fitting Chennai, ASTM B366 N08825 Incoloy 825 Fittings Suppliers Chennai, Incoloy 825 Buttweld Fittings Chennai, ASTM B366 WPNICMC Fittings India, Incoloy 825 Elbow Fittings Chennai, UNS N08825 Tee Fittings Dealer India, Alloy 825 Fittings Stockists Chennai, India.
Incoloy 825 Pipe Fittings Specification
Incoloy 825 Pipe Fittings Chemical Composition
| The Chemical Composition of Incoloy 825 Pipe Fittings, % | |
|---|---|
| Nickel | 38.0-46.0 |
| Iron | ≥22.0 |
| Chromium | 19.5-23.5 |
| Molybdenum | 2.5-3.5 |
| Copper | 1.5-3.0 |
| Titanium | 0.6-1.2 |
| Carbon | ≤0.05 |
| Manganese | ≤1.00 |
| Sulfur | ≤0.030 |
| Silicon | ≤0.50 |
| Aluminum | ≤0.20 |
Incoloy 825 Pipe Fittings Mechanical Properties
| Tensile Strength, min. | Yield Strength, min. | Elongation, min. | Elastic Modulus | |||
|---|---|---|---|---|---|---|
| Mpa | % | Gpa | 106psi | ksi | Mpa | ksi |
| 690 | 45 | 206 | 29.8 | 100 | 310 | 45 |
Incoloy 825 Pipe Fittings Equivalent Indian Standard
| STANDARD | AFNOR | EN | OR | WERKSTOFF NR. | UNS | JIS | BS | GOST |
| Incoloy 825 Pipe Fittings | NFE30C20DUM | NiCr21Mo | XH38BT | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 |
Incoloy 825 Pipe Fittings generally consist of 38–46% nickel, 19.5–23.5% iron, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3.0% copper, and 0.6–1.2% titanium. This alloy offers superior resistance to phosphoric and sulfuric acids, pitting, crevice corrosion, intergranular attack, and stress-corrosion cracking. The alloy has good mechanical properties over a wide range of temperature and is easy to fabricate and weld.
Distributors of Incoloy 825 Buttweld Pipe Fittings in India, ASTM B366 N08825 Equal Tee Chennai, 825 Incoloy® Alloy Welded Pipe Fittings Suppliers Chennai, Werkstoff Nr. 2.4858 Concentric Reducer Chennai, 800HT Incoloy 825 45°/90°/180° Butt weld Elbow India, Nickelvac® 825 Pipe Fittings Chennai, Alloy 825 Buttweld Pipe Nipple India, High-Quality ASME B366 Incoloy N08825 Stub End Chennai, India.
Largest Incoloy 825 Pipe Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Incoloy 800/ 800H/ 800HT Pipe Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Why Choose Incoloy 825 Pipe Fittings from Meet Fittings?
Incoloy 825 Pipe Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
UNS N08825 Elbow And Most Reliable Alloy 825 Tubing Fittings India, Incoloy 825 Pipe Fitting Chennai, ASTM B366 N08825 Incoloy 825 Fittings Suppliers Chennai, Incoloy 825 Buttweld Fittings Chennai, ASTM B366 WPNICMC Fittings India, Incoloy 825 Elbow Fittings Chennai, UNS N08825 Tee Fittings Dealer India, Alloy 825 Fittings Stockists Chennai, India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Incoloy 825 pipe fittings offer several advantages, making them ideal for demanding applications. They provide exceptional resistance to corrosion, including pitting, crevice corrosion, and intergranular attack, even in harsh acidic and oxidizing environments. Their high nickel content ensures resistance to stress corrosion cracking, while molybdenum enhances protection against chloride-induced corrosion. These fittings maintain excellent mechanical strength and stability across a wide temperature range. Additionally, they are durable, easy to fabricate, and cost-effective, ensuring long-term reliability in industries like chemical processing, marine engineering, and oil and gas exploration.
Standard Dimensions Of Alloy 825 Pipe Fittings
| NPS (Normal Pipe Size) | O.D. (Outside Daimeter) | Elbow 90 Deg | Elbow 45 Deg | Return Elbow 180 Deg | ||||
|---|---|---|---|---|---|---|---|---|
| (inch) | Long Radius Elbow | Short Radius | Long Radius Elbow | Long Radius Elbow | ||||
| (millimeter/ MM) | (inch./ Inches) | Center to Face (Inches) | Center to Face (Inches) | Center to Face (Inches) | Radius (Inches) | Center to Center (Inches) | Back to face (Inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Alloy 825 Pipe Fittings Weight Chart Table
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Types of Incoloy 825 Pipe Fittings
Are Custom Sizes Available for Incoloy 825 Pipe Fittings?
Yes, custom sizes for Incoloy 825 Pipe Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Distributors of Incoloy 825 Buttweld Pipe Fittings in India, ASTM B366 N08825 Equal Tee Chennai, 825 Incoloy® Alloy Welded Pipe Fittings Suppliers Chennai, Werkstoff Nr. 2.4858 Concentric Reducer Chennai, 800HT Incoloy 825 45°/90°/180° Butt weld Elbow India, Nickelvac® 825 Pipe Fittings Chennai, Alloy 825 Buttweld Pipe Nipple India, High-Quality ASME B366 Incoloy N08825 Stub End Chennai, India.
Application Industry of Incoloy 825 Pipe Fittings
Incoloy 825 Pipe Fittings have extensive applications in equipment that deals with acidic and corrosive media like heat exchangers, pickling units, chemical tanks, piping systems in nuclear fuel reprocessing, and offshore oil and gas platforms. The fittings create leak-free and stable connections in severe service conditions. Its extended service life, along with superior corrosion resistance and strength, renders Incoloy 825 pipe fittings an efficient and economical answer to demanding industrial conditions.
