Stainless Steel 310/310S Forged Fittings Manufacturer and Supplier in Chennai, India
Based in Chennai, India, we take pride in being a reliable manufacturer and supplier of Stainless Steel 310/310S Forged Fittings. Our products are crafted to be high-quality and heat-resistant, making them perfect for critical industrial applications. Renowned for their outstanding performance in high-temperature and oxidizing environments, our SS 310/310S forged fittings find their place in various sectors, including petrochemical, power generation, and furnace manufacturing. We utilize advanced forging techniques and adhere to global standards to ensure that our fittings are durable, reliable, and precisely dimensioned. With a strong commitment to quality, timely delivery, and customer satisfaction, we cater to clients across India and beyond, providing expertly engineered stainless steel solutions.
Table of Contents
Stainless Steel 310 Threaded Fitting Price List in Chennai, UNS S31000 Stainless Steel Forged Fittings Supplier in India, Stainless Steel 310S High Pressure Forged Fittings Exporter in Chennai, Stainless Steel 310 Hex Plug Supplier in Chennai, SS 310 Threaded Pipe Elbow Exporter in Chennai, SS UNS S31008 Pipe Nipple Size Chart, Stainless Steel 310S Forged Fittings Price in India, SS 310 Screwed Fittings in Chennai, Stainless Steel 1.4841 Forged Fittings Supplier in Chennai, Stainless Steel 310S Hexagonal Plug Stockist in India, Stainless Steel 310S Forged Fittings Exporter in India
Stainless Steel 310/310S Forged Fittings Specification
| Specification | ASTM A182 / ASME SA182 |
| Dimension Standard | ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799 |
| Size | 1/8″ NB to 4″ NB |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Pressure-Temperature Class | Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS. |
Our Stainless Steel 310/310S Forged Fittings are made up of 24–26% chromium and 19–22% nickel, with 310S featuring a lower carbon content (≤0.08%) compared to 310 (≤0.25%). This design choice enhances weldability and minimizes the risk of carbide precipitation. These fittings excel in resisting oxidation, sulfidation, and thermal fatigue at temperatures reaching up to 1100°C. Their mechanical properties include a minimum tensile strength of 515 MPa, yield strength of 205 MPa, and an elongation of 40%. We offer a variety of product types, including forged elbows, tees, couplings, unions, caps, and crosses, all engineered to endure high temperatures and pressure.
Stainless Steel 310/310S Forged Fittings Chemical Compostion
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 – 26.00 | 0.75 max | 19.00 – 21.00 | 53.095 min |
Stainless Steel 310/310S Forged Fittings Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
SS 310 Socket Weld Fittings Exporter in India, DIN 1.4841 Stainless Steel Union Price List in Chennai, Stainless Steel 310 Forged Fittings Supplier in India, ANSI B16.11 Stainless Steel 310S Forged Fittings Exporter in Chennai, Stainless Steel 310 Forged Elbow Exporter in Chennai, Stainless Steel 310 Forged Tee in India, SS 310 Socket Weld Fittings Size Chart, Stainless Steel 310 Coupling Price in India, UNS S31000 Stainless Steel Forged Threaded 90 deg. Elbow Weight Chart, Stainless Steel 310S Stainless Steel Cross Trader Supplier in Chennai, Stainless Steel 310 Socket weld Fittings Stockist in India
Largest Stainless Steel 310/310S Forged Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Stainless Steel 310/310S Forged Fittings in Chennai, India. We offer an extensive range of Stainless Steel 310/310S Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Stainless Steel 310/310S Forged Fittings Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
Pressure Ratings of Stainless Steel 310/310S Forged Fittings
| Pressure-Temperature | |||||
| Temperature | Class | ||||
| 150 | 300 | ||||
| 1/4 – 1 inch. | 1 1/4 – 2 inch. | 2 1/2 – 3 inch. | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | – | 935 | 750 | 560 |
| 450 | 232 | – | 725 | 600 | 475 |
| 500 | 260 | – | 510 | 450 | 385 |
| 550 | 288 | – | 300 | 300 | 300 |
Why Choose Stainless Steel 310/310S Forged Fittings from Meet Fittings?
Choose Stainless Steel 310/310S Forged Fittings from Meet Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Stainless Steel UNS S31008 Full Coupling Exporter in India, SS 310 Forged Socket weld Fittings Sizes in mm, Stainless Steel 310 Forged Fittings Manufacturer in Chennai, Stainless Steel DIN 1.4845 Threaded Fittings Supplier in Chennai, ASME SA182 Stainless Steel 310S Forged Fittings Price List in Chennai, SUS 310 Forged Union Distributor in Chennai, SS UNS S31003 Forged Fittings Supplier in Chennai, Stainless Steel 310 Forged Cap Distributor in India
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Stainless steel 310/310S forged fittings provide excellent high heat resistance, making them ideal for heat-intensive applications. Their high chromium and nickel content provide outstanding corrosion and oxidation resistance even in extreme environments. These materials exhibit remarkable strength, rigidity and strength, maintaining structural integrity under thermal cycles. The low carbon content of the 310S variant increases weldability and reduces the risk of sensitization. Their versatility is suitable for a variety of industries including petrochemicals, power generation and furnace construction. Easy to manufacture and maintain, these products last longer, reducing downtime and maintenance costs.
Types of Stainless Steel 310/310S Forged Fittings
Are Custom Sizes Available for Stainless Steel 310/310S Forged Fittings?
Yes, custom sizes for Stainless Steel 310/310S Forged Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in
Dimension of SS 310/310S Forged Fittings
| ASME b16.9 Fittings Normal Pipe Size | ANSI b16 9 Pipe Fitting O D Y | Wall Thickness T (Pipe Elbow Sch.) | LR 45 Deg Elbows Centre to Face B | SR 45 Deg Elbows Weight | LR 90 Deg Elbows Centre to Face A | LR 90 Deg Elbows Weight In Below | SR 90 Deg Elbows Centre to Face A | SR 90 Deg Elbows Weight In Below | ||
| mm | inch | mm | mm | Schedule | mm | kg | mm | kg | mm | kg |
| 15 | 1/2” | 21.3 | 2.78 | STD | 15.9 | 0.04 | 38.1 | 0.08 | – | – |
| 3.73 | X.S | 15.9 | 0.05 | 38.1 | 0.10 | – | – | |||
| 20 | 3/4” | 26.7 | 2.87 | STD | 11.1 | 0.04 | 28.6 | 0.08 | – | – |
| 3.91 | X.S | 11.1 | 0.05 | 28.6 | 0.11 | – | – | |||
| 25 | 1” | 33.4 | 3.38 | STD | 22.2 | 0.09 | 38.1 | 0.15 | 25.4 | 0.11 |
| 4.55 | X.S | 22.2 | 0.11 | 38.1 | 0.19 | 25.4 | 0.14 | |||
| 32 | 11/4” | 42.2 | 3.56 | STD | 25.4 | 0.14 | 47.6 | 0.28 | 31.75 | 0.18 |
| 4.85 | X.S | 25.4 | 0.2 | 47.6 | 0.39 | 31.75 | 0.24 | |||
| 40 | 11/2” | 48.3 | 3.68 | STD | 28.6 | 0.2 | 57.1 | 0.4 | 38.1 | 0.26 |
| 5.08 | X.S | 28.6 | 0.25 | 57.1 | 0.5 | 38.1 | 0.35 | |||
| 50 | 2” | 60.3 | 3.91 | STD | 34.9 | 0.36 | 76.2 | 0.72 | 50.8 | 0.5 |
| 5.54 | X.S | 34.9 | 0.5 | 76.2 | 1.0 | 50.8 | 0.68 | |||
| 65 | 21/2” | 73.0 | 5.16 | STD | 44.4 | 0.73 | 95.2 | 1.46 | 63.5 | 0.95 |
| 7.01 | X.S | 44.4 | 0.91 | 95.2 | 1.82 | 63.5 | 1.27 | |||
| 80 | 3” | 88.9 | 5.49 | STD | 50.8 | 1.1 | 114.3 | 2.18 | 76.2 | 1.45 |
| 7.62 | X.S | 50.8 | 1.45 | 114.3 | 2.86 | 76.2 | 1.95 | |||
| 100 | 4” | 114.3 | 6.02 | STD | 63.5 | 2.1 | 152.4 | 4.2 | 101.6 | 2.8 |
| 8.56 | X.S | 63.5 | 2.9 | 152.4 | 5.7 | 101.6 | 3.9 | |||
| 125 | 5” | 141.3 | 6.65 | STD | 79.4 | 3.4 | 190.0 | 6.8 | 127.0 | 4.8 |
| 9.5 | X.S | 79.4 | 5.0 | 190.0 | 10.0 | 127.0 | 6.5 | |||
| 150 | 6” | 168.3 | 7.11 | STD | 95.2 | 5.1 | 229.0 | 10.1 | 152.4 | 6.8 |
| 10.97 | X.S | 95.2 | 7.7 | 229.0 | 15.3 | 152.4 | 10.2 | |||
| 200 | 8” | 219.1 | 8.18 | STD | 127.0 | 10.2 | 305.0 | 20.4 | 203.0 | 13.6 |
| 12.7 | X.S | 127.0 | 15.5 | 305.0 | 30.9 | 203.0 | 20.9 | |||
| 250 | 10” | 273.9 | 9.27 | STD | 159.0 | 18.1 | 381.0 | 36.1 | 254.0 | 24.1 |
| 12.7 | X.S | 159.0 | 24.4 | 381.0 | 48.8 | 254.0 | 32.5 | |||
| 300 | 12” | 323.9 | 9.52 | STD | 190.0 | 26.6 | 457.0 | 53.1 | 305.0 | 35.4 |
| 12.7 | X.S | 190.0 | 35.0 | 457.0 | 70.0 | 305.0 | 46.7 | |||
| 350 | 14” | 355.6 | 9.52 | STD | 222.0 | 34.1 | 533.0 | 68.1 | 356.0 | 45.4 |
| 12.7 | X.S | 222.0 | 45.0 | 533.0 | 90.0 | 356.0 | 60.0 | |||
| 400 | 16” | 406.4 | 9.52 | STD | 254.0 | 45.0 | 610.0 | 89.3 | 406.0 | 59.5 |
| 12.7 | X.S | 254.0 | 59.0 | 610.0 | 118.0 | 406.0 | 78.7 | |||
| 450 | 18” | 457.0 | 9.52 | STD | 286.0 | 56.5 | 686.0 | 113.0 | 457.0 | 75.6 |
| 12.7 | X.S | 286.0 | 75.0 | 686.0 | 150.0 | 457.0 | 100.0 | |||
| 500 | 20” | 508.0 | 9.52 | STD | 318.0 | 85.0 | 762.0 | 140.0 | 508.0 | 93.5 |
| 12.7 | X.S | 318.0 | 112.5 | 762.0 | 186.0 | 508.0 | 124.0 | |||
| 600 | 24” | 610.00 | 9.52 | STD | 381.0 | 101.5 | 914.0 | 203.0 | 610.0 | 135.0 |
| 12.7 | X.S | 381.0 | 134.5 | 914.0 | 269.0 | 610.0 | 179.0 | |||
Stainless Steel 310/310S Forged Fittings Size
| NPS (inch) | Pipe Schedule. | OD (inch) | Wall Thick. (in) | Temperature | ||||
| 100 Fitting | 200 Fitting | 300 Fitting | 400 Fitting | 500 Fitting | ||||
| Allowable Stress | ||||||||
| 16700 | 16700 | 16700 | 15500 | 14400 | ||||
| 1″ | 40 | 1.315 | 0.133 | 2205 | 2205 | 2205 | 2047 | 1902 |
| 80 | 1.315 | 0.179 | 3061 | 3061 | 3061 | 2841 | 2640 | |
| 160 | 1.315 | 0.250 | 4493 | 4493 | 4493 | 4170 | 3874 | |
| 1 1/2″ | 40 | 1.900 | 0.145 | 1629 | 1629 | 1629 | 1512 | 1404 |
| 80 | 1.900 | 0.200 | 2303 | 2303 | 2303 | 2138 | 1986 | |
| 160 | 1.900 | 0.281 | 3362 | 3362 | 3362 | 3120 | 2899 | |
| 2″ | 40 | 2.375 | 0.154 | 1371 | 1371 | 1371 | 1272 | 1182 |
| 80 | 2.375 | 0.218 | 1985 | 1985 | 1985 | 1843 | 1712 | |
| 160 | 2.375 | 0.344 | 3283 | 3283 | 3283 | 3047 | 2831 | |
| 3″ | 40 | 3.500 | 0.216 | 1301 | 1301 | 1301 | 1208 | 1122 |
| 80 | 3.500 | 0.300 | 1844 | 1844 | 1844 | 1712 | 1590 | |
| 160 | 3.500 | 0.438 | 2787 | 2787 | 2787 | 2587 | 2403 | |
| 4″ | 40 | 4.500 | 0.237 | 1102 | 1102 | 1102 | 1023 | 950 |
| 80 | 4.500 | 0.337 | 1596 | 1596 | 1596 | 1482 | 1377 | |
| 160 | 4.500 | 0.531 | 2611 | 2611 | 2611 | 2424 | 2552 | |
| 5″ | 40 | 5.563 | 0.258 | 965 | 965 | 965 | 896 | 832 |
| 80 | 5.563 | 0.375 | 1428 | 1428 | 1428 | 1325 | 1231 | |
| 160 | 5.563 | 0.625 | 2474 | 2474 | 2474 | 2296 | 2133 | |
| 6″ | 40 | 6.625 | 0.280 | 877 | 877 | 877 | 814 | 756 |
| 80 | 6.625 | 0.432 | 1379 | 1379 | 1379 | 1280 | 1189 | |
| 160 | 6.625 | 0.719 | 2382 | 2382 | 2382 | 2211 | 2054 | |
| 8″ | 40 | 8.625 | 0.322 | 771 | 771 | 771 | 716 | 665 |
| 80 | 8.625 | 0.500 | 1218 | 1218 | 1218 | 1131 | 1050 | |
| 160 | 8.625 | 0.906 | 2298 | 2298 | 2298 | 2133 | 1982 | |
| 10″ | 40 | 10.750 | 0.365 | 699 | 699 | 699 | 649 | 603 |
| 80 | 10.750 | 0.594 | 1159 | 1159 | 1159 | 1075 | 999 | |
| 160 | 10.750 | 1.125 | 2289 | 2289 | 2289 | 2124 | 1974 | |
ASTM A182 SS 310 End Cap Supplier in Chennai, Stainless Steel 310 Forged Pipe Fittings Weight Chart, Stainless Steel 310S Welding Boss Exporter in India, Stainless Steel 310 High Pressure Forged Fitting Manufacturer in Chennai, WERKSTOFF NR. 1.4845 Threaded Cross Price List in Chennai, Stainless Steel 310 Threaded Fittings Sizes in mm, Stainless Steel 310S Forged Fittings Distributor in Chennai, Stainless Steel 310S 180 Deg. Street Elbow in India, Stainless Steel 310 Forged Tee Distributor in India.
Application Industry of Stainless Steel 310/310S Forged Fittings
Stainless Steel 310/310S Forged Fittings are perfect for extreme heat environments where strength and resistance to thermal degradation are essential. They are commonly used in applications such as furnace components, heat exchangers, burner assemblies, kilns, and incinerators. In the petrochemical and refining industries, these fittings deliver exceptional performance in high-temperature processing units and reformers. The SS 310S variant, with its lower carbon content, is particularly advantageous in welded structures to mitigate carbide precipitation. Thanks to their robust forged construction, they are well-suited for pressure systems that experience continuous thermal cycling and exposure to corrosive gases.
