Nickel Alloy 201 Buttweld Fittings Manufacturer and Supplier in Chennai, India
Meet Fittings, Chennai, India-based, is a renowned manufacturer and supplier of *Nickel Alloy 201 Buttweld Fittings*, which provide very strong and corrosion-proof piping solutions for harsh industrial settings. These fittings are made of Nickel 201—a commercially pure wrought nickel alloy possessing superior mechanical properties, high resistance to corrosive media, and high thermal and electrical conductivity. Meet Fittings provides a full line of buttweld fittings such as elbows, tees, reducers, and caps, all carefully designed to conform to international specifications. The company serves industries like chemical processing, electronics, marine, food processing, and production of synthetic fibers.
Table of Contents
Nickel Alloy 201 Buttweld Concentric Reducer Manufacturer in Chennai, Nickel Alloy 201 Butt weld Elbow 180 Deg Thickness, ANSI B16.9 Nickel 201 Butt weld Elbow 180 Deg Supplier in Chennai, UNS N02201 Buttweld Elbow 90 Deg Exporter in India, ASTM B366 201 Buttweld Concentric Reducer Price List in Chennai, Nickel Alloy Concentric Reducers Distributor in Chennai, ASTM B366 201 Butt weld Equal Tee Supplier in Chennai, Nickel Alloy 201 Butt weld End Cap Distributor in India, UNS N02201 Butt weld Elbow Nipple Sizes in mm
Nickel Alloy 201 Buttweld Fittings Specification
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
The Nickel Alloy 201 Buttweld Fittings are highly pure with at least 99.6% nickel and a content of carbon and other alloy elements that is less than 0.02%. It highly resists caustic alkalies and reducing chemicals, as well as showing great mechanical strengths in tensile strength in the order of 403 MPa and yield strength as high as 103 MPa in most applications. Low in carbon, this alloy boasts more resistance to graphitization and can thus be allowed to be highly exposed at elevated temperatures over 315°C in being embrittled.
Nickel Alloy 201 Buttweld Fittings Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
Nickel Alloy 201 Buttweld Fittings Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Nickel Alloy 201 Buttweld Concentric Reducer Supplier in India, ANSI B16.9 Nickel 201 Butt weld Eccentric Reducer Exporter in Chennai, Nickel Alloy 201 Butt weld End Cap Exporter in India, Nickel Alloy 201 Buttweld Fittings Exporter in Chennai, Nickel Alloy 201 Buttweld Concentric Reducer in India, ASTM B366 201 Butt weld Equal Tee Size Chart, Nickel 201 Butt weld Eccentric Reducer Price in India, Nickel Alloy 201 Butt weld End Cap Weight Chart, Nickel 201 Butt weld Eccentric Reducer Supplier in Chennai, UNS N02201 Buttweld Elbow 90 Deg Stockist in India, Nickel Alloy 201 Buttweld Equal Tee Supplier in India, Nickel Alloy 201 Buttweld Stub End Fitting Price List in Chennai
Largest Nickel Alloy 201 Buttweld Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Nickel Alloy 201 Buttweld Fittings in Chennai, India. We offer an extensive range of Nickel Alloy 201 Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Nickel Alloy 201 Buttweld Fittings Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
Why Choose Nickel Alloy 201 Buttweld Fittings from Meet Fittings?
Nickel Alloy 201 Buttweld Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 201 Buttweld Equal Tee Thickness, ANSI B16.9 Nickel 201 Butt weld Elbow 180 Deg Supplier in Chennai, ASTM B366 201 Butt weld Equal Tee Stockist in India, Nickel Alloy 201 Buttweld Concentric Reducer Exporter in India, ANSI B16.9 Nickel 201 Butt weld Eccentric Reducer Price List in Chennai, Nickel Alloy 201 Buttweld Elbow 90 Deg Supplier in India, Nickel Alloy 201 Buttweld Elbow 45 Deg Dealer in Chennai, UNS N02201 Butt weld Elbow Nipple Supplier in Chennai, ASTM B366 201 Buttweld Concentric Reducer Exporter in Chennai, Nickel Alloy 201 Buttweld Concentric Reducer Size Chart, Werkstoff Nr. 2.4068 Buttweld Concentric Reducer Price in India
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Nickel Alloy 201 Buttweld Fittings offer excellent corrosion resistance, especially in acidic and high-temperature environments. Known for their outstanding strength and durability, they maintain their integrity even in harsh conditions, making them ideal for chemical, petrochemical, and food processing industries. The fittings provide excellent weldability, ensuring smooth and reliable joints. They also exhibit high electrical and thermal conductivity, adding to their versatility. With low carbon content, Nickel Alloy 201 Buttweld Fittings resist carbide precipitation, ensuring longevity and minimal maintenance in critical applications.
Types of Nickel Alloy 201 Buttweld Fittings
Are Custom Sizes Available for Nickel Alloy 201 Buttweld Fittings?
Yes, custom sizes for Nickel Alloy 201 Buttweld Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Dimensions of Nickel Alloy 201 Buttweld Fittings
| Nominal PipeSize | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| (inches) | – | Long Radius | Short Radius | Long Radius | Long Radius | |||
| (mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | 7/16 | 2 1/4 | 1 11/16 | ||
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Sizes of Nickel Alloy 201 Buttweld Fittings
| NPS (inch) | Pipe Sch. | Wall Thk. (in) | OD (inch) | Temperature | ||||
|---|---|---|---|---|---|---|---|---|
| 100 | 200 | 300 | 400 | 500 | ||||
| Allowable Stress (Pressure Rating) | ||||||||
| 16700 | 16700 | 16700 | 15500 | 14400 | ||||
| 1″ | 40 | 0.133 | 1.315 | 2205 | 2205 | 2205 | 2047 | 1902 |
| 80 | 0.179 | 1.315 | 3061 | 3061 | 3061 | 2841 | 2640 | |
| 160 | 0.250 | 1.315 | 4493 | 4493 | 4493 | 4170 | 3874 | |
| 1 1/2″ | 40 | 0.145 | 1.900 | 1629 | 1629 | 1629 | 1512 | 1404 |
| 80 | 0.200 | 1.900 | 2303 | 2303 | 2303 | 2138 | 1986 | |
| 160 | 0.281 | 1.900 | 3362 | 3362 | 3362 | 3120 | 2899 | |
| 2″ | 40 | 0.154 | 2.375 | 1371 | 1371 | 1371 | 1272 | 1182 |
| 80 | 0.218 | 2.375 | 1985 | 1985 | 1985 | 1843 | 1712 | |
| 160 | 0.344 | 2.375 | 3283 | 3283 | 3283 | 3047 | 2831 | |
| 3″ | 40 | 0.216 | 3.500 | 1301 | 1301 | 1301 | 1208 | 1122 |
| 80 | 0.300 | 3.500 | 1844 | 1844 | 1844 | 1712 | 1590 | |
| 160 | 0.438 | 3.500 | 2787 | 2787 | 2787 | 2587 | 2403 | |
| 4″ | 40 | 0.237 | 4.500 | 1102 | 1102 | 1102 | 1023 | 950 |
| 80 | 0.337 | 4.500 | 1596 | 1596 | 1596 | 1482 | 1377 | |
| 160 | 0.531 | 4.500 | 2611 | 2611 | 2611 | 2424 | 2552 | |
| 5″ | 40 | 0.258 | 5.563 | 965 | 965 | 965 | 896 | 832 |
| 80 | 0.375 | 5.563 | 1428 | 1428 | 1428 | 1325 | 1231 | |
| 160 | 0.625 | 5.563 | 2474 | 2474 | 2474 | 2296 | 2133 | |
| 6″ | 40 | 0.280 | 6.625 | 877 | 877 | 877 | 814 | 756 |
| 80 | 0.432 | 6.625 | 1379 | 1379 | 1379 | 1280 | 1189 | |
| 160 | 0.719 | 6.625 | 2382 | 2382 | 2382 | 2211 | 2054 | |
| 8″ | 40 | 0.322 | 8.625 | 771 | 771 | 771 | 716 | 665 |
| 80 | 0.500 | 8.625 | 1218 | 1218 | 1218 | 1131 | 1050 | |
| 160 | 0.906 | 8.625 | 2298 | 2298 | 2298 | 2133 | 1982 | |
| 10″ | 40 | 0.365 | 10.750 | 699 | 699 | 699 | 649 | 603 |
| 80 | 0.594 | 10.750 | 1159 | 1159 | 1159 | 1075 | 999 | |
| 160 | 1.125 | 10.750 | 2289 | 2289 | 2289 | 2124 | 1974 | |
Nickel Alloy 201 Butt weld End Cap Manufacturer in Chennai, ASTM B366 201 Buttweld Concentric Reducer Price List in Chennai, ASTM B366 201 Butt weld Equal Tee Sizes in mm, Nickel Alloy 201 Butt weld End Cap Distributor in Chennai, Nickel Alloy 201 Buttweld Concentric Reducer in India, Nickel Alloy 201 Buttweld Concentric Reducer Distributor in India, ASTM B366 201 Buttweld Concentric Reducer Supplier in Chennai, ANSI B16.9 Nickel 201 Butt weld Elbow 180 Deg Weight Chart, Nickel Alloy 201 Buttweld Elbow Nipple Exporter in India
Application Industry of Nickel Alloy 201 Buttweld Fittings
Nickel Alloy 201 Buttweld Fittings are widely used in industries that handle caustic soda, salt, food chemicals, and high-purity solvents. Common applications include evaporators, reactors, heat exchangers, marine equipment, synthetic fiber production, and electronics manufacturing. These fittings provide strong, leak-proof joints and resist corrosion in highly alkaline and mildly acidic environments. Their thermal stability and stress corrosion cracking resistance render them perfectly suitable for high-reliability systems requiring long-term performance and dependability in chemically aggressive environments.
