Inconel Forged Fittings Manufacturer and Supplier in Chennai, India
Meet Fittings, Chennai, India, is a renowned manufacturer and supplier of **Inconel Forged Fittings** with high performance solutions for severe environments of high pressure, temperature, and corrosion. Produced using superior Inconel grades like Inconel 600, 625, and 825, these forged fittings offer great resistance to heat, oxidation, and corrosion. Meet Fittings offers a wide assortment of Inconel forged fittings that include socket weld as well as threaded elbows, tees, couplings, unions, plugs, and bushings. These fittings are used extensively in petrochemical, aerospace, marine, and power generation industries where the long-term strength and leak-tight performance are a must.
Table of Contents
Inconel Forged Fittings Price List in Chennai, Inconel Alloy 600 Equal Tee, Inconel Forged Fittings Supplier in India, Inconel Forged Fittings Exporter in Chennai, Inconel Forged Fittings Supplier in Chennai, Inconel Forged Fittings Exporter in Chennai, Inconel Forged Fittings Size Chart, Manufacturer Of ASTM B564 601 Inconel Bushing, Inconel Forged Fittings Price in India, Inconel Forged Fittings in Chennai, Inconel Forged Fittings Supplier in Chennai, Inconel Forged Fittings Stockist in India, Inconel Forged Fittings Exporter in India
Inconel Forged Fittings Specification
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
Inconel Forged Fittings consist mainly of nickel, with different levels of chromium, iron, molybdenum, and niobium based on the grade. These alloys exhibit excellent resistance to oxidation, pitting, and stress-corrosion cracking in acidic as well as high-temperature conditions. Inconel 625, for instance, possesses tensile strength up to 827 MPa and maintains superior mechanical properties in a wide temperature range from cryogenic to high conditions above 1000°C.
Inconel Forged Fittings Chemical Compostion
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
Inconel Forged Fittings Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Inconel Forged Fittings Exporter in India, Inconel ASTM B564 625 Cross, Inconel Forged Fittings Price List in Chennai, Inconel Forged Fittings Supplier in India, Inconel Forged Fittings Exporter in Chennai, 718 Inconel Full Couplings, Inconel Forged Fittings Exporter in Chennai, Inconel Forged Fittings in India, Inconel Forged Fittings Size Chart, Inconel Forged Fittings Price in India, BS 3799 Union, Inconel Forged Fittings Weight Chart, Inconel Forged Fittings Supplier in Chennai, Inconel Forged Fittings Stockist in India.
Largest Inconel Forged Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Inconel Forged Fittings in Chennai, India. We offer an extensive range of Inconel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Inconel Forged Fittings Equivalent Grade
| STANDARD | UNS | EN | WERKSTOFF NR. | GOST | JIS | BS | AFNOR |
| Inconel 600 | N06600 | NiCr15Fe | 2.4816 | МНЖМц 28-2,5-1,5 | NCF 600 | NA 13 | NC15FE11M |
| Inconel 601 | N06601 | NiCr23Fe | 2.4851 | XH60BT | NCF 601 | NA 49 | NC23FeA |
| Inconel 625 | N06625 | NiCr22Mo9Nb | 2.4856 | ХН75МБТЮ | NCF 625 | NA 21 | NC22DNB4M |
| Inconel 718 | N07718 | – | 2.4668 | – | – | – | – |
Why Choose Inconel Forged Fittings from Meet Fitttings?
Choose Inconel Forged Fittings from Meet Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Inconel Forged Fittings Dimensions Chart
| NPS (Normal Pipe Size) | O.D. (Outside Daimeter) | Elbow 90 Deg | Elbow 45 Deg | Return Elbow 180 Deg | ||||
|---|---|---|---|---|---|---|---|---|
| (inch) | Long Radius Elbow | Short Radius | Long Radius Elbow | Long Radius Elbow | ||||
| (millimeter/ MM) | (inch./ Inches) | Center to Face (Inches) | Center to Face (Inches) | Center to Face (Inches) | Radius (Inches) | Center to Center (Inches) | Back to face (Inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Inconel Forged Fittings Exporter in India, Werkstoff No 2.4816 Inconel High Pressure Forged Fittings, Inconel Forged Fittings Sizes in mm, Inconel Forged Fittings Manufacturer in Chennai, Inconel Forged Fittings Thickne Alloy Steel Weld Neck, Inconel Forged Fittings Supplier in Chennai, Inconel Forged Fittings Price List in Chennai, Inconel Forged Fittings Distributor in Chennai, Inconel Forged Fittings Supplier in Chennai, Inconel Forged Fittings Distributor in India
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Inconel Forged Fittings offer numerous advantages, making them ideal for demanding applications. Their exceptional resistance to oxidation, corrosion, and extreme temperatures ensures durability in harsh environments. These fittings exhibit superior mechanical strength, maintaining performance under high-pressure and high-stress conditions. With excellent weldability and machinability, they allow for precise installation and customization. Additionally, their resistance to pitting, crevice corrosion, and chloride-induced stress corrosion cracking enhances reliability in chemical, marine, and aerospace industries. Inconel Forged Fittings provide long-term performance, reducing maintenance needs and ensuring operational efficiency in critical systems.
Inconel Forged Fittings Size Chart
| O.D. or I.D. Diameter | Equivalent Decimal | Nominal Diameter | Typical Threads In Inch |
| 5/16 | 0.313 | 1/16 | 27 |
| 13/32 | 0.405 | 1/8 | 27 |
| 35/64 | 0.540 | 1/4 | 18 |
| 43/64 | 0.675 | 3/8 | 18 |
| 27/32 | 0.840 | 1/2 | 14 |
| 1-3/64 | 1.050 | 3/4 | 14 |
| 1-5/16 | 1.315 | 1 | 11-1/2 |
| 1-21/32 | 1.660 | 1-1/4 | 11-1/2 |
| 1-29/32 | 1.900 | 1-1/2 | 11-1/2 |
| 2-3/8 | 2.375 | 2 | 11-1/2 |
| 2-7/8 | 2.875 | 2-1/2 | 8 |
| 3-1/2 | 3.500 | 3 | 8 |
| 4 | 4.000 | 3-1/2 | 8 |
| 4-1/2 | 4.500 | 4 | 8 |
Types of Inconel Forged Fittings
Are Custom Sizes Available for Inconel Forged Fittings?
Yes, custom sizes for Inconel Forged Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Inconel Forged Fittings Supplier in Chennai, Inconel Forged Fittings Weight Chart, Inconel Forged Fittings Exporter in India, Inconel 600 Forged 90 Deg Screwed Threaded Elbow, Inconel Forged Fittings Manufacturer in Chennai, Inconel Forged Fittings Price List in Chennai, Inconel Forged Fittings Sizes in mm, Inconel Forged Fittings Distributor in Chennai, Inconel Forged Fittings in India, Inconel Forged Fittings Distributor in India
Appllication Industry of Inconel Forged Fittings
Inconel Forged Fittings are employed in high-performance applications like heat exchangers, offshore platforms for oil, nuclear reactors, exhaust ducting, and chemical processing systems. Their mechanical strength and resistance to corrosion in adverse conditions provide safe and trouble-free performance. They offer strong, leak-free connections in high-pressure piping systems, lowering maintenance and downtime. Due to their superior thermal stability, corrosive attack resistance, and resistance to mechanical shock, Inconel forged fittings are an ideal selection for highly critical industrial applications.
