Inconel 625 Buttweld Fittings Manufacturer and Supplier in Chennai, India
Fittings Meet, Chennai, India-based, is a prominent manufacturer and supplier of *Inconel 625 Buttweld Fittings*, providing high-performance piping items suitable for extreme pressure, temperature, and corrosion. Made from Inconel 625—a nickel-chromium-molybdenum-niobium alloy—these fittings are renowned for their exceptional strength, weldability, and corrosion resistance in a broad spectrum of aggressive environments. Meet Fittings provides an extensive line of buttweld fittings including elbows, tees, reducers, crosses, and caps, all designed to international standards. These products find extensive applications in critical industries like marine, aerospace, chemical processing, nuclear reactors, and offshore oil & gas.
Table of Contents
Inconel 625 Pipe Elbow In India, Inconel 625 Pipe Fittings Chennai, Alloy 625 Buttweld Elbow Chennai, Inconel N06625 Seamless Fittings Exporter West ,Chennai, Inconel 2.4856 Butt Weld Pipe Fittings in India, Inconel® Alloy 625 Two Joint Pipe Fittings Chennai, 625 Inconel Welded Fittings Manufacturers in India, India.
Inconel 625 Buttweld Fittings Specification
| Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
Inconel 625 Buttweld Fittings consist of about 58% nickel, 20–23% chromium, 8–10% molybdenum, and 3.15–4.15% niobium. This blend offers better resistance against corrosion from oxidizing and reducing agents, coupled with better strength and fatigue resistance throughout a wide range of temperature. These fittings are capable of bearing up to 930 MPa tensile strength and a yield strength of about 517 MPa, making them perfect for high-stress and corrosive environments. The alloy also exhibits resistance to pitting, crevice corrosion, and chloride-induced stress corrosion cracking.
Inconel 625 Buttweld Fittings Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
Inconel 625 Buttweld Fittings Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 705 | 42.5 % |
Equivalent Grades for 625 Inconel Pipe Fitting
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GHOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Inconel Alloy 625 Butt weld Fittings India, ASTM B366 Inconel 625 Butt Weld Fittings Supplier in Chennai, Inconel 2.4856 Buttweld Pipe Fittings Chennai, Alloy 625 Butt Weld Pipe Cap Chennai, Inconel 625 Equal Tee India, Nickel Alloy 625 SR Elbow Exporter in Chennai, UNS N06625 Stub End India, Inconel 625 Eccentric Reducer In Chennai, India.
Largest Inconel 625 Buttweld Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Inconel 625 Buttweld Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Inconel 625 Buttweld Fittings Dimensions Standard
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Inconel 625 Buttweld Fittings Pressure Rating Chart
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Why Choose Inconel 625 Buttweld Fittings from Meet Fittings?
Inconel 625 Buttweld Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
625 Inconel Reducer in India, ASTM B366 Inconel 625 Butt Weld Cross in Chennai, ANSI B16.9 Inconel Alloy 625 Pipe Fittings Chennai, Inconel 625 Pipe Bend Stockist in Chennai, Inconel 625 Pipe Nipple Manufacturer & Exporter in India, Inconel 625 Buttweld Fittings Chennai, ASTM B366 Inconel 625 Butt Weld Cross in India.
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Inconel 625 Buttweld Fittings offer several key advantages, including exceptional resistance to oxidation, corrosion, and high-temperature environments, making them ideal for demanding applications. Their superior strength and durability ensure reliability in industries such as aerospace, marine, and chemical processing. Inconel 625’s excellent fatigue and thermal-fatigue properties provide long-lasting performance, even under extreme conditions. The alloy also boasts excellent weldability and formability, enabling seamless integration into piping systems. These fittings maintain structural integrity and performance, ensuring minimal maintenance and enhanced operational efficiency in challenging environments.
Types of Inconel 625 Buttweld Fittings
Are Custom Sizes Available for Inconel 625 Buttweld Fittings?
Yes, custom sizes for Inconel 625 Buttweld Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Inconel 625 Pipe Elbow In India, Inconel 625 Pipe Fittings Chennai, Alloy 625 Buttweld Elbow Chennai, Inconel N06625 Seamless Fittings Exporter West ,Chennai, Inconel 2.4856 Butt Weld Pipe Fittings in India, Inconel® Alloy 625 Two Joint Pipe Fittings Chennai, 625 Inconel Welded Fittings Manufacturers in India, India.
Application Industry of Inconel 625 Buttweld Fittings
Inconel 625 Buttweld Fittings are widely utilized in demanding applications like seawater piping systems, heat exchangers, power plants, flue gas scrubbers, chemical reactors, and exhaust systems. The capacity to endure severe environments, such as acidic media, and high temperatures, renders them most suitable for critical applications. Such fittings offer robust, leak-tight connections and a long shelf life, guaranteeing efficiency and safety in harsh industrial environments. Their corrosion resistance, mechanical stability, and versatility position them as a number one for critical mission piping systems.
