Inconel 617 Buttweld Fittings Manufacturer and Supplier in Chennai, India
Meet Fittings, India-based, is a reliable producer and supplier of *Inconel 617 Buttweld Fittings*, providing top-performance solutions for applications where high strength, heat resistance, and corrosion resistance are needed. Inconel 617 nickel-chromium-cobalt-molybdenum alloy-based fittings are designed to resist extreme temperature and severe chemical environments. Meet Fittings provides a comprehensive assortment of buttweld fittings such as elbows, tees, reducers, crosses, and caps that are manufactured to international quality standards. The fittings find extensive applications in power generation, petrochemical plants, aerospace systems, and high-temperature process equipment.
Table of Contents
Inconel 617 Pipe Bend In India, ANSI B16.9 Inconel 617 Welded Buttweld Fittings Chennai, Inconel UNS N06617 Seamless Pipe Fittings Chennai, Inconel® Alloy 617 180 Deg bend Chennai, Inconel® Alloy 617 Pipe bend Supplier in India, Inconel® Alloy 617 Equal Tee Chennai, Inconel 617 Pipe Fittings India, ASME SB366 Inconel 617 Long Stub In India,
Inconel 617 Buttweld Fittings Specification
Inconel 617 Pipe Fittings Specifications |
||
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
Inconel 617 Buttweld Fittings consist of about 50–60% nickel, 20–24% chromium, 10–15% cobalt, and 8–10% molybdenum with minor amounts of aluminum. The special composition provides excellent mechanical strength (tensile strength of up to 760 MPa), high oxidation and carburization resistance, and excellent creep resistance up to 1100°C. The alloy also provides excellent metallurgical stability and is thus applicable for both continuous and cyclic exposure under high temperatures.
Inconel 617 Buttweld Fittings Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 617 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 1.0 max | balance | 58.0-63.0 | 21.0-25.0 |
Inconel 617 Buttweld Fittings Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 617 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Equivalent Grades for 617 Inconel Pipe Fitting
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 617 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
Alloy 617 Short Radius Elbow Supplier In India, Inconel 10d Pipe Bend Chennai, Inconel WERKSTOFF NR.2.4851 Cross Exporter in Chennai, 617 Inconel Alloy End Cap Chennai, Inconel 617 Pipe Bend India, Inconel 617 Pipe Elbow Chennai, Supplier of Inconel 617 45 degree Elbow India, 617 Inconel Reducer India, ASTM B366 617 Inconel Alloy 90 degree Elbow Exporters and Suppliers in Chennai, India.
Largest Inconel 617 Buttweld Fittings Supplier in Chennai, India
Meet Fittings is a leading supplier of Inconel 617 Buttweld Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
If You Are Looking To Buy High Quality
Inconel 617 Buttweld Fittings Dimensions Standard
| Nominal Pipe Size | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| (inches) | Long Radius | Short Radius | Long Radius | Long Radius | ||||
| (mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Inconel 617 Buttweld Fittings Pressure Rating Chart
| NPS (inch) | Pipe Sch. | Wall Thk. (in) | OD (inch) | Temperature | ||||
|---|---|---|---|---|---|---|---|---|
| 100 | 200 | 300 | 400 | 500 | ||||
| Allowable Stress (Pressure Rating) | ||||||||
| 16700 | 16700 | 16700 | 15500 | 14400 | ||||
| 1″ | 40 | 0.133 | 1.315 | 2205 | 2205 | 2205 | 2047 | 1902 |
| 80 | 0.179 | 1.315 | 3061 | 3061 | 3061 | 2841 | 2640 | |
| 160 | 0.250 | 1.315 | 4493 | 4493 | 4493 | 4170 | 3874 | |
| 1 1/2″ | 40 | 0.145 | 1.900 | 1629 | 1629 | 1629 | 1512 | 1404 |
| 80 | 0.200 | 1.900 | 2303 | 2303 | 2303 | 2138 | 1986 | |
| 160 | 0.281 | 1.900 | 3362 | 3362 | 3362 | 3120 | 2899 | |
| 2″ | 40 | 0.154 | 2.375 | 1371 | 1371 | 1371 | 1272 | 1182 |
| 80 | 0.218 | 2.375 | 1985 | 1985 | 1985 | 1843 | 1712 | |
| 160 | 0.344 | 2.375 | 3283 | 3283 | 3283 | 3047 | 2831 | |
| 3″ | 40 | 0.216 | 3.500 | 1301 | 1301 | 1301 | 1208 | 1122 |
| 80 | 0.300 | 3.500 | 1844 | 1844 | 1844 | 1712 | 1590 | |
| 160 | 0.438 | 3.500 | 2787 | 2787 | 2787 | 2587 | 2403 | |
| 4″ | 40 | 0.237 | 4.500 | 1102 | 1102 | 1102 | 1023 | 950 |
| 80 | 0.337 | 4.500 | 1596 | 1596 | 1596 | 1482 | 1377 | |
| 160 | 0.531 | 4.500 | 2611 | 2611 | 2611 | 2424 | 2552 | |
| 5″ | 40 | 0.258 | 5.563 | 965 | 965 | 965 | 896 | 832 |
| 80 | 0.375 | 5.563 | 1428 | 1428 | 1428 | 1325 | 1231 | |
| 160 | 0.625 | 5.563 | 2474 | 2474 | 2474 | 2296 | 2133 | |
| 6″ | 40 | 0.280 | 6.625 | 877 | 877 | 877 | 814 | 756 |
| 80 | 0.432 | 6.625 | 1379 | 1379 | 1379 | 1280 | 1189 | |
| 160 | 0.719 | 6.625 | 2382 | 2382 | 2382 | 2211 | 2054 | |
| 8″ | 40 | 0.322 | 8.625 | 771 | 771 | 771 | 716 | 665 |
| 80 | 0.500 | 8.625 | 1218 | 1218 | 1218 | 1131 | 1050 | |
| 160 | 0.906 | 8.625 | 2298 | 2298 | 2298 | 2133 | 1982 | |
| 10″ | 40 | 0.365 | 10.750 | 699 | 699 | 699 | 649 | 603 |
| 80 | 0.594 | 10.750 | 1159 | 1159 | 1159 | 1075 | 999 | |
| 160 | 1.125 | 10.750 | 2289 | 2289 | 2289 | 2124 | 1974 | |
Why Choose Inconel 617 Buttweld Fittings from Meet Fittings?
Inconel 617 Buttweld Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Inconel 617 Pipe Bend In India, ANSI B16.9 Inconel 617 Welded Buttweld Fittings Chennai, Inconel UNS N06617 Seamless Pipe Fittings Chennai, Inconel® Alloy 617 180 Deg bend Chennai, Inconel® Alloy 617 Pipe bend Supplier in India, Inconel® Alloy 617 Equal Tee Chennai, Inconel 617 Pipe Fittings India, ASME SB366 Inconel 617 Long Stub In India,
Customer Support
Largest Inventory
On Time Deliveries
ISO Certified
Inconel 617 Buttweld Fittings offer several advantages, making them ideal for high-temperature and corrosive environments. Their excellent oxidation and carburization resistance ensure longevity in extreme conditions. The alloy maintains superior strength, even at temperatures up to 2000°F (1093°C), making it suitable for high-stress applications. Inconel 617 also exhibits outstanding creep resistance and weldability, ensuring reliable performance in industries like aerospace, power generation, and chemical processing. Additionally, the fittings provide exceptional resistance to thermal fatigue and corrosion, reducing maintenance costs and enhancing system efficiency.
Types of Inconel 617 Buttweld Fittings
Are Custom Sizes Available for Inconel 617 Buttweld Fittings?
Yes, custom sizes for Inconel 617 Buttweld Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.
Alloy 617 Short Radius Elbow Supplier In India, Inconel 10d Pipe Bend Chennai, Inconel WERKSTOFF NR.2.4851 Cross Exporter in Chennai, 617 Inconel Alloy End Cap Chennai, Inconel 617 Pipe Bend India, Inconel 617 Pipe Elbow Chennai, Supplier of Inconel 617 45 degree Elbow India, 617 Inconel Reducer India, ASTM B366 617 Inconel Alloy 90 degree Elbow Exporters and Suppliers in Chennai, India.
Application Industry of Inconel 617 Buttweld Fittings
Inconel 617 Buttweld Fittings are best suited for severe applications like gas turbines, heat exchangers, reformers, furnace parts, and chemical processing equipment. Its resistance to oxidation, sulfidation, and high-temperature corrosion provides leak-tight, dependable connections in high-performance piping systems. The fittings offer extended service life with low maintenance even under thermal cycling and corrosive environments. These are renowned for their high strength, heat stability, and corrosion resistance. Inconel 617 fittings are the first choice for industries operating in the most challenging service conditions.
