Inconel 600 Buttweld Fittings Manufacturer and Supplier in Chennai, India

Based in Chennai, India, we take pride in being a reliable manufacturer and supplier of Inconel 600 Buttweld Fittings. Our products are designed to withstand the rigors of high temperatures and harsh chemical environments, offering durability and corrosion resistance. Inconel 600 is a nickel-chromium-iron alloy celebrated for its remarkable resistance to oxidation, corrosion, and stress corrosion cracking caused by chlorides. We ensure that our buttweld fittings are precision-engineered to comply with international standards like ASTM B366, making them a popular choice in power plants, chemical industries, aerospace, and heat treatment systems. Thanks to our advanced production capabilities, we consistently deliver top-notch quality, precise dimensions, and outstanding mechanical performance for even the most demanding applications.

Distributors of Inconel® 600 ASME SB366 Buttweld Reducer in India, Inconel 600 Equal Tee Wholesaler Chennai, 600 Nickel Alloy Buttweld Tee Dealer Chennai, Inconel Grade 600 Butt weld Pipe Fittings Stockists Chennai, Alloy 600 Pipe Fittings Suppliers India, 600 Inconel Welded Pipe Fittings Suppliers Chennai, 600 Inconel Unequal Cross Exporters India, Nickelvac® 600 Pipe Fittings Chennai, India.

Inconel 600 Buttweld Fittings Specification

Specifications	ASTM B366 / ASME SB366
Dimension Standard	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
ASME B16.9	standard for – Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends.
ASME B16.28	standard for – Butt-Welded Short Radius Elbows & Returns Bends
MSS SP-43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Size Range	½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Seamless Butt Weld Fitting Size	1/2″ – 10″
Welded Butt Weld Fittings Size	1/2″ – 48″
Thickness	Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type	Seamless / Welded / Fabricated

Our Inconel 600 Buttweld Fittings are crafted from a high-performance alloy that contains about 72% nickel, 14–17% chromium, and 6–10% iron. This unique combination provides exceptional resistance to high-temperature oxidation, corrosion in both acidic and alkaline environments, and stress corrosion cracking. The mechanical properties are impressive, featuring a tensile strength of around 655 MPa, yield strength of 310 MPa, and an elongation of 30–45%. We offer a variety of types, including elbows, tees, reducers, caps, and stub ends, available in both seamless and welded forms, all designed to ensure smooth flow and robust weld joints in pressure piping systems.

Inconel 600 Buttweld Fittings Chemical Composition

Grade		C	Mn	Si	Fe	S	Cr	Cu	Ni
600	min.	–	–	–	6.0	–	14.0	–	72.0
600	max.	0.15	1.0	0.5	10.0	0.015	17.0	0.5	–

Inconel 600 Buttweld Fittings Equivalent Grade

Grade	UNS No	Old British		Euronorm		GOST	Japanese JIS
		BS	En	No	AFNOR
Inconel 600	N06600	NA 13	NiCr15Fe	2.4816	NC15FE11M	МНЖМц 28-2,5-1,5	NCF 600

UNS N06600 Inconel® Alloy Butt weld Seamless Pipe Fitting In India, Inconel Pipe Fittings Chennai, ASTM B366 Inconel 600 Pipe Elbow Chennai, Inconel® Alloy 600 Buttweld Fittings Chennai, Inconel Alloy Butt weld Pipe Fittings India, 600 Inconel® 45°/90°/180° Butt weld Elbow Chennai, 600 Nickel Alloy ANSI B16.9 Short & Long Radius Elbow India, ASME B16.28 600 Inconel® Alloy Butt weld Reducing Tee Chennai, India.

Largest Inconel 600 Buttweld Fittings Supplier in Chennai, India

Meet Fittings is a leading supplier of Inconel 600 Buttweld Fittings in Chennai, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Inconel 600 Buttweld Fittings Dimensions Standard

NOMINAL PIPE SIZE	ALL FITTINGS	ALL FITTINGS	ELBOWS AND TEES	180 DEG RETURN BENDS	180 DEG RETURN BENDS	180 DEG RETURN BENDS	REDUCERS	CAPS
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Centre -to- End Dimension A, B, C, M	Centre-to- Centre O	Back-to- Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	0.19	…	…	…	0.19	0.38

Steel Buttweld Fittings Pressure Rating Chart

NPS (inch)	Pipe Sch.	Wall Thk. (in)	OD (inch)	Temperature
				100	200	300	400	500
				Allowable Stress (Pressure Rating)
				16700	16700	16700	15500	14400
1″	40	0.133	1.315	2205	2205	2205	2047	1902
	80	0.179	1.315	3061	3061	3061	2841	2640
	160	0.250	1.315	4493	4493	4493	4170	3874
1 1/2″	40	0.145	1.900	1629	1629	1629	1512	1404
	80	0.200	1.900	2303	2303	2303	2138	1986
	160	0.281	1.900	3362	3362	3362	3120	2899
2″	40	0.154	2.375	1371	1371	1371	1272	1182
	80	0.218	2.375	1985	1985	1985	1843	1712
	160	0.344	2.375	3283	3283	3283	3047	2831
3″	40	0.216	3.500	1301	1301	1301	1208	1122
	80	0.300	3.500	1844	1844	1844	1712	1590
	160	0.438	3.500	2787	2787	2787	2587	2403
4″	40	0.237	4.500	1102	1102	1102	1023	950
	80	0.337	4.500	1596	1596	1596	1482	1377
	160	0.531	4.500	2611	2611	2611	2424	2552
5″	40	0.258	5.563	965	965	965	896	832
	80	0.375	5.563	1428	1428	1428	1325	1231
	160	0.625	5.563	2474	2474	2474	2296	2133
6″	40	0.280	6.625	877	877	877	814	756
	80	0.432	6.625	1379	1379	1379	1280	1189
	160	0.719	6.625	2382	2382	2382	2211	2054
8″	40	0.322	8.625	771	771	771	716	665
	80	0.500	8.625	1218	1218	1218	1131	1050
	160	0.906	8.625	2298	2298	2298	2133	1982
10″	40	0.365	10.750	699	699	699	649	603
	80	0.594	10.750	1159	1159	1159	1075	999
	160	1.125	10.750	2289	2289	2289	2124	1974

Why Choose Inconel 600 Buttweld Fittings from Meet Fittings?

Inconel 600 Buttweld Fittings from Meet Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Ferrochronin® 600 Pipe Fittings In India, 600 Inconel® Concentric Reducer Chennai, Alloy 600 MSS-SP-43 Buttweld Swage Nipple Chennai, MSS SP-79 Inconel 600 End Pipe Cap Suppliers Chennai, Inconel® JIS NCF 600 Stub Ends Exporters India, Werkstoff No 2.4816 Inconel® Alloy Butt weld Eccentric Reducer Traders Chennai, Inconel 600 Buttweld Fittings India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Inconel 600 Buttweld Fittings offer numerous advantages, including exceptional resistance to oxidation, carburization, and high-temperature corrosion, making them ideal for extreme environments. They provide excellent strength and stability at elevated temperatures, up to 2000°F (1093°C), ensuring reliable performance. The alloy’s high nickel content enhances its resistance to stress corrosion cracking and chloride-induced corrosion. Additionally, Inconel 600 fittings are highly durable, with superior weldability and fabricability, making them suitable for critical applications in industries like aerospace, chemical processing, and power generation. Their longevity and reliability reduce maintenance costs and downtime.

Types of Inconel 600 Buttweld Fittings

Are Custom Sizes Available for Inconel 600 Buttweld Fittings?

Yes, custom sizes for Inconel 600 Buttweld Fittings are available at Meet Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@meetfitings.co.in.

UNS N06600 Inconel® Alloy Butt weld Seamless Pipe Fitting In India, Inconel Pipe Fittings Chennai, ASTM B366 Inconel 600 Pipe Elbow Chennai, Inconel® Alloy 600 Buttweld Fittings Chennai, Inconel Alloy Butt weld Pipe Fittings India, 600 Inconel® 45°/90°/180° Butt weld Elbow Chennai, 600 Nickel Alloy ANSI B16.9 Short & Long Radius Elbow India, ASME B16.28 600 Inconel® Alloy Butt weld Reducing Tee Chennai, India.

Application Industry of Inconel 600 Buttweld Fittings

Inconel 600 Buttweld Fittings are perfect for applications that involve high heat and aggressive media. They find extensive use in heat exchangers, steam generators, nuclear reactors, furnace components, chemical processing equipment, and aerospace systems. Their ability to perform reliably under cyclic heating and cooling makes them well-suited for environments prone to thermal fatigue. These fittings excel in both oxidizing and reducing conditions, standing up to exposure from organic and inorganic acids, alkalis, and chlorides. With a blend of strength, ductility, and corrosion resistance, Inconel 600 buttweld fittings are the go-to choice for high-integrity, long-lasting industrial piping systems.
